उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| प्रकार:: | माइक्रो-कंप्यूटर नियंत्रण स्वचालित डीजल जेनरेटर | ठंडा करने की विधि: | पानी की मदद से ठंडा करने वाले उपकरण |
|---|---|---|---|
| उत्पादन का प्रकार: | एसी थ्री फेज़ | रफ़्तार: | 1500prm 50Hz |
| उपयोग की शर्तें: | भूमि उपयोग | इकाई का प्रकार: | स्वचालन प्रकार |
| उत्तेजना मोड: | स्व उत्साहित | निर्यात बाजार: | दक्षिण पूर्व एशिया, मध्य पूर्व, |
| आघात: | चार स्ट्रोक | इंस्टॉलेशन तरीका: | तय |
| प्रमुखता देना: | marine diesel genset,Marine Genset |
||
• Economical: Cummins Marine Diesel Generator is one of the lowest fuel consumption in the world.
• High reliability and long life span.
• Perfect starting ability: Can start successfully at -10 Degree Centigrade without any accessories.
• Perfect low load condition: The air inlet system choose "HELLO" technical to improve burning performance and reduce fuel consumption.
• Convenient maintenance: simple & reliable structures and L line cylinders provides convenient maintenance and inspection .
• Can provide certificates of Marine Products, conforming to IACS (International Association of Classification Societies)
CUMMINS Marine Genset Model List :
Specification:
| 1. Specification of genset | ||||||||
| Gensets model | CCFJ100J | |||||||
| Rated power | 100KW | |||||||
| Rated voltage | 400/230V | |||||||
| Rated current | 180A | |||||||
| Rated frequency(HZ) | 50 | |||||||
| Rated speed | 1500rpm | |||||||
| Power factor | 0.8(lagging) | |||||||
| Dimensions(mm) (L×W×H) | 2250*850*1400 | |||||||
| Genset weight(kg) | 1500 | |||||||
| 2. Specification of diesel engine | ||||||||
| Engine brand | DCEC Cummins | |||||||
| Engine model | 6CT8.3-GM115 | |||||||
| Number of Cylinders | 6 | |||||||
| Cylinder arrangement | Vertical in-line | |||||||
| Cycle | Four stroke | |||||||
| Aspiration | Turbocharged | |||||||
| Bore×Stroke (mm×mm) | 114 x 135 | |||||||
| Displacement (Liter) | 8.3 | |||||||
| Rated power | 115KW | |||||||
| Rated speed | 1500rpm | |||||||
| Starting Method | DC24V electrical starting | |||||||
| Speed Governor | Electronic | |||||||
| Cooling System | By sea water heat exchanger | |||||||
| Fuel Consumption | 212g/kw.h | |||||||
| 3. Specification of alternator | ||||||||
| Alternator brand | Stamford | |||||||
| Alternator model | UCM274E/125 | |||||||
| Number of Phase | 3 | |||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||
| Number of Bearing | 1 | |||||||
| Protection Grade | IP23 | |||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||
| Insulation Class | H | |||||||
Global Power Service:
1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience
of more than 10 years. Our total production capacity is about 20,000 units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000
fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator
sets as per your specific requirements.
4. We provide professional & in time service after sale.
